April 29, 2010

Losi Night Crawler Bind-N-Drive

Losi Night Crawler Bind-N-Drive

While other crawlers require some modifications before they’re ready for the rocks, the 1/10-scale Night Crawler BND from Losi is good to go right out of the box, just bind it to your DSM-equipped transmitter. Included is an electronics package with a LiPo compatible, crawler programmed ESC that features voltage cutoff, so both your vehicle and battery will be protected. Powering this crawler is easier than ever, a 540-sized crawler-specific 55T motor and high-torque metal gear steering servo will get you up and over obstacles in no time. Plus, a worm-gear drive with a smaller differential case gives you increased ground clearance.

Losi Night Crawler Bind-N-Drive

Specification:
Type: Rock Crawler
Scale: 1/10 (2.2)
Length: 444.5mm (17.5 in)
Width: 250.8mm (9.875 in)
Wheelbase: 312.4mm (12.3 in)
Weight: 1.9kg (4.18 lb)
Chassis: Aluminum twin vertical plate
Suspension: 4-link
Tyre Type: 2.2 Losi Rock Claw tyres
Motor or Engine: 55T/540-sized motor
Speed Control: Losi MSC12L Fwd/Rev LiPo-compatible with crawler programming
Radio: Included Losi receiver with Spektrum 2.4GHz DSM technology
Wheel Size: 2.2-inch beadlock
Kit/RTR: BND
Shock Type: Adjustable 4-inch aluminium, coil-over, oil-filled
Body: Pre-decorated Grappler Pro

Losi Night Crawler Bind-N-Drive

Losi Night Crawler Bind-N-Drive

Features:
– The front and rear solid axle features a worm gear drive that acts as a brake when no power is supplied
– The included ESC, with crawler-specific programming, accepts NiMH and LiPo batteries
– All-metal CV front axle and centre driveshafts provide superior durability to the driveline to handle the stresses of rock crawling
– The included Losi receiver with Spektrum 2.4GHz DSM technology means you’ll never have to worry about radio interference
– The included front and rear LED light set comes pre-wired and mounted to the chassis
– 4″ adjustable aluminium shocks provide durable, smooth operation and maximum suspension articulation without binding
– The crawler features a low-centre-of-gravity battery tray design that allows for multiple battery types—from NiMH and LiPo “stick” packs to any of the 2.2-inch Losi LiPo crawler battery packs
– The molded 4-link suspension setup minimizes rear axle swing and provides more precise handling
– True 3-piece 2.2 beadlock chrome wheels, with 12mm hexes, hold the tyre bead in place and let you change tyres if needed—all without glue
– National Champion 2.2 Losi Rock Claw tyres with foam inserts are constructed with Losi’s blue compound and have the characteristics, grip and traction to scale even the toughest courses
– The direct-drive transmission provides an ultra-low gear ratio for rock crawling and metal outputs for durability
– The twin vertical plate chassis is anodised red for a custom look
– Zero Ackerman steering provides class leading performance with 45 degrees of steering throw
– The competition-legal Grappler Pro body features realistic looks and added functionality

Source: Horizon Hobby [horizonhobby.co.uk]
