October 16, 2017

3DRC SF3 & YR-10 Fan Boosters and Diffusors

3DRC have expanded their range of 3-D-printed Formula Fan Boosters and diffusers by making these parts accessible for Serpent SF3 and YR-10 owners also. The Fan Boosters are available for 30mm fan units, which are intended for Formula racing classes, while the 40mm variant targets the new 200mm LMP class. The fan mounts attach to the rear motor pod and the 30mm variants are available with or without integrated diffusor while the 40mm booster is a non-diffusor affair.

Also new and coming for the SF3 and YR-10 is a large rear diffusor that is attached to the power pod side plates, which allows to use a multitude of wings and wing heights as they will not interfere with the diffusor. The part is 3-D-printed from tough yet flexible material and it will add scale looks and additional downforce. Both items are available through 3DRC’s Shapeways store or at select hobby shops.

Source: 3DRC [shapeways.com]
