June 19, 2023

Xpress Arrow AM1 M-Chassis

Hong Kong chassis manufacturer Xpress has released a new M-Chassis, the Arrow AM1.  The shaft driven car is an M-Chassis version of the full size Arrow AT1 1:10 electric touring car.  Sporting all the designs that made the Arrow AT1 a competitive chassis, they have turned it into a M-Chassis platform.  The AM1 features 4WD Shaft Drive Floating Gearbox System with a sealed transmission gearbox with drive via aluminium propeller shafts which providing extra durability and weight saving.  It uses the same self-lubricating plastic that is found on Arrow AT1 with suspension plastics the same as the XM1, so Xpress mini fans will have parts already.


Internal Gear Ratio: 2.353

4WD Shaft Drive Floating Gear Box System

Sealed Transmission Gear Box

Front Spool & Rear Gear Differential Unit

Front & Rear Aluminum Propeller Shaft

Low CG Roll Bar Design

Low CG Front & Rear Aluminium Shock Tower

Low Profile Long Travel Aluminium Short Shocks

Aluminium Insert Adjusted Ackermann Steering Bridge

Front Spring Steel Double Joint Universal Shaft

Full Low Friction Drive Gears

Full Aluminium Suspension Mount

2.25mm Graphite Main Chassis

2.0mm Graphite Top Deck

Full Turnbuckle Linkages

Full Ball Bearing Set

Adjustable Battery Position


Type: Competition Grade 1:10 On-road 4WD

Length: 315mm

Wheelbase: 225mm

Track Width: F160mm / R160mm (Approx.)

Source: Xpress [rc-xpress.com]
