September 23, 2022

Xray X12 ‘23

Xray have today unveiled the 2023 edition of their 1:12 platform, the X12. The All-new chassis features extra forward position for centre pivot for improved cornering speed and steering response. It also features extra mounting position for the side braces between the front and centre position for extra fine tuning of the car flex which improves steering response and cornering speed. The ’23 chassis is shortened by 3.5mm in front with extra chamfer, which eliminates chassis dragging and improves cornering speed. It now has 4 positions for the front battery backstop in 2mm steps instead of the groove to prevent the battery stop from moving in hard crashes. The rear POD plate features redesigned area of the alu POD plate pivot holder for improved durability of the POD plate. It features 2 centring holes instead of 1 to eliminate tweak issues in crashes. The bulkheads has been completely redesigned to achieve maximum low CG and weight to improve stability and eliminate tweaking issues in serious crashes and are 5mm lower and 4g lighter compared to the previous version. In total the car features 24 new improvements.

View the X12 ’23 presentation here for complete details

August 26, 2022

Xray all new NT1‘23

Xray have today unveiled the 2023 edition of their 1:10 nitro touring car chassis the NT1. A big year for the nitro touring car class with the World Championship coming up in November in Thailand, the car features an all-new chassis with narrowed front suspension pivots to increase stability & traction. Hard composite suspension arms combined with the improved central chassis flex keeps the suspension geometry stable while the flex is transferred through chassis and radio plate to maintain traction. Lower down-stop mounting holders without the eccentric geometry make the car easier to set suspension down-stops. All-new front aluminium bulkheads accommodate new upper arm holder with adjustable flex. The redesigned front upper arm holder features new roll centre positions in all 9 positions. An ultra-compact and super lightweight receiver box moves the weight lower and closer to the centre of the chassis. The radio plate has new servo holders that move the throttle servo more rearwards, the steering servo more frontwards and receiver box to a more central location. A simplified aluminium 2-speed shaft holders eliminate unnecessary braces to make the chassis more flexible, while the wider positioning provide improved support for the 2 speed shaft. New rear aluminium bulkheads have a 2mm front/rear wheelbase adjustment for easy traction tuning depending on the track conditions, front position more traction, rear position more stability. Longer rear suspension pins allow a wide range of wheelbase adjustment.

View the NT1’23 presentation here for complete details

August 12, 2022

Xray all new X1‘23 1:10 Formula Chassis

Xray have today unveiled the 2023 edition of their 1:10 EP Formula chassis the X1. The all new X1’23 gets a new front suspension design featuring innovative CFF upper arms with improved flex characteristics and integrated camber adjustments. A new chassis accommodates the CFF front suspension, a redesigned battery backstop and revised wheelbase setting with reinforced chassis areas. A one-piece central front bulkhead integrates the steering arm mount and optimised wheelbase adjustments for simplicity. CFF front upper arms make the X1 extremely responsive & sharp, generate fantastic cornering speed & traction, and simplify the camber adjustment process for easy setup changes. The front upper arm mount allows for easier caster adjustments and top side installation for much easier assembly and maintenance. Also new is a redesigned centre top deck with easier mounting. The battery mounting system secures the pack without O-ring or tape in a tweak-free, floating manner that improves traction and consistency, and features new low profile lightweight bushings for a sleeker look and lower CG. The car features a redesigned independent wing mount system which is machined from harder carbon fibre material for more stable handling and features 2 centering pins for more secure assembly. New side braces are mounted using low profile bushings to eliminate M3 nuts.

View the X1’23 presentation here for complete details.

August 11, 2022

Xray XB8 ‘Frontward’ composite rear wing

Xray have released a new ‘Frontward’ design rear wing suitable for their 1:8 Offroad chassis’. The XB8 molded wing features the forward position which helps to create downforce on rear wheels to increase rear traction. The shape of the wing increases the stability of the car in all conditions and is legal under the latest IFMAR wing specifications. Made from a special composite mixture, the wing was designed to survive severe abusive and extreme crashes while keeping its shape.

Source: Xray [teamxray.com]

August 4, 2022

Xray X4 Roll Centre Spacers

Xray have released new front & rear roll centre spacers for the X4 for placement below the lower suspension arms. Allowing quick, precise & hassle-free ride height adjustment they improve steering when used in front and improve rotation when used in rear. Xray claim the also improve graphite durability in crashes when used in the front.

Source: Xray [teamxray.com]

July 29, 2022

Xray RX8E’23 1/8th EP onroad chassis

Following last week’s release of the new for 2023 RX8, Xray have today unveiled the EP version of the same car, the RX8E’23. The car is a major update on its predecessor with only a few parts carrying over from the old car. The all new chassis has narrowed front suspension pivots to increase stability & traction, more chassis cutouts to create greater flex in desired locations and additional chassis cutouts to improve engine cooling. Hard composite suspension arms combined with the improved central chassis flex keeps the suspension geometry stable while the flex is transferred through chassis and radio plate to maintain traction. Narrower front suspension holders help improve geometry, while longer lower suspension arm shock mounting holders compensate for the narrower suspension holders to maintain the ideal shock absorber geometry. Lower down-stop mounting holders without the eccentric geometry make the car easier to set suspension down-stops. There is all-new front aluminium bulkheads with a lowered design and new front upper clamps that feature integrated upper shock mounting positions, eliminating the need for a separate front shock tower. An innovative front upper shock mounting directly on the upper clamps adjusted via shims provide more flex on front suspension. A new front upper bulkhead brace for easy flex adjustments. More stability with the brace installed, more traction and steering when the brace is removed. There is an ultra-compact and super lightweight receiver box that moves the weight lower and closer to the centre of the chassis. Plus many more changes that make up the all new RX8E.

View the RX8E’23 presentation here for complete details.

July 26, 2022

Xray XB8 low suspension mounting LSM arms

New from Xray for the XB8 are these low suspension mounting LSM arms. Suitable for very rough & bumpy tracks, they help gain traction & stability and offer consistent handling in rough terrain. Available in a hard composite version for low traction conditions, there is also a graphite alternative for high traction conditions. Fits the XB8’17 onwards, XB8E’17 onwards, GTX.2 onwards and GTXE.2 onwards.

View the different options here

July 22, 2022

Xray RX8’23 1/8th nitro onroad chassis

Xray have announced their all new RX8’23 1/8th nitro onroad platform. The car is a major update on its predecessor with only a few parts carrying over from the old car. The all new chassis has narrowed front suspension pivots to increase stability & traction, more chassis cutouts to create greater flex in desired locations and additional chassis cutouts to improve engine cooling. Hard composite suspension arms combined with the improved central chassis flex keeps the suspension geometry stable while the flex is transferred through chassis and radio plate to maintain traction. Narrower front suspension holders help improve geometry, while longer lower suspension arm shock mounting holders compensate for the narrower suspension holders to maintain the ideal shock absorber geometry. Lower down-stop mounting holders without the eccentric geometry make the car easier to set suspension down-stops. There is all-new front aluminium bulkheads with a lowered design and new front upper clamps that feature integrated upper shock mounting positions, eliminating the need for a separate front shock tower. An innovative front upper shock mounting directly on the upper clamps adjusted via shims provide more flex on front suspension. A new front upper bulkhead brace for easy flex adjustments. More stability with the brace installed, more traction and steering when the brace is removed. There is an ultra-compact and super lightweight receiver box that moves the weight lower and closer to the centre of the chassis. The radio plate with new servo holders moves the throttle servo more rearwards with a more central location for the receiver box. Plus many more changes that make up the all new RX8.

View the RX8’23 presentation here for complete details.
