Team Magic have released their new E4RS II Evo 190mm TC chassis. The new evolution focuses on lowering the car’s centre of gravity with other changes also following the current trend of centrally mounting all the major elements to avoid uneven flex of the chassis such as the servo mount. The 2.3mm carbon main chassis is slightly narrower than its predecessor and looking at the car you can see it comes highly spec’d with aluminium and carbon throughout as well TiNi coated shock shafts, front double jointed drive shafts and a rear gear differential.

Team Magic E4RS II Evo TC chassis

Features
New – Lowered and optimized centre of gravity
New – Centred and realigned masses
Perfectly symmetric Flex
Exclusive “Zero flex interference” concept
New – Central flex points
New – 3D flex system (optional)
New – Narrow High Grade 2.3mm woven graphite chassis
New – High Grade 2.0mm woven graphite upper deck
New – High Grade woven graphite shock towers
New – Mirror polished short dampers
New – Titanium coated shock shafts
Kfactory matched shock springs
New – Optimized anti-roll bar mounts
Aluminium 7075 lower bulkheads
New – Aluminium 7075 upper bulkhead with optimized roll center
New – Hard suspension arms and uprights
New – Hard plastic caster blocks
Fully adjustable arm mounts
ST steel hardened suspension axle
Fully adjustable arm positions and angles

Team Magic E4RS II Evo TC chassis

New – Aluminium 7075 one-piece floating servo mount
Aluminium 7075 ball raced steering bellcrank
New – Aluminium 7075 laterally adjustable motor mount
New – Aluminium 7075 optimized center layshaft mounting blocks
Aluminium 7075 hard coated spur gear holder
CNC machined Delrin Spur Gear
Low Friction belts
Adjustable belt tension via eccentrics
New – Front spool axle with hard treated steel outdrives
New – Gear differential with 4 composite gears
New – Front double-jointed driveshafts
Rear hard treated steel CVD driveshafts
Aluminium 7075 wheel hex adapters
Quick release battery holder
High Grade graphite battery retainers (3 positions)
Low Friction ball bearings
Heavy duty body posts
High density foam bumper

Team Magic E4RS II Evo TC chassis

Team Magic E4RS II Evo TC chassis

Team Magic E4RS II Evo TC chassis

Team Magic E4RS II Evo TC chassis

Team Magic E4RS II Evo TC chassis
